Power and performance – The qualities of a champion

• Powerful 600 W motor for tough applications
• All ball bearing construction for long lifetime
• High strength & precision sintered bearing bracket for precision working

Technical data

Rated input power	600 W
No-load speed, 1st gear	0 – 2,600 rpm
Power output	360 W
Weight	1.7 kg
Rated torque	20.0 Nm
Drill spindle connecting thread	1/2"-20 UNF
Chuck capacity, min./max.	1.5 – 13 mm
Tool dimensions (width)	66 mm
Tool dimensions (length)	252 mm
Tool dimensions (height)	196 mm

Drilling range

Drilling diameter in aluminium	13 mm
Drilling diameter in wood	30 mm
Drilling diameter in steel	13 mm

Noise/vibration information

Noise level

The A-rated noise level of the power tool is typically as follows: Sound pressure level dB(A); Sound power level dB(A). Uncertainty K= dB.
